Specification
| Product Attribute | Attribute Value |
| PPAP | Unknown |
| SVHC | Yes |
| EU RoHS | Compliant with Exemption |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 2 |
| Automotive | Yes |
| PCB changed | 2 |
| Part Status | Unconfirmed |
| Configuration | Single |
| Package Width | 3.95(Max) |
| Direction Type | Uni-Directional |
| Package Height | 1.1(Max) |
| Package Length | 4.6(Max) |
| Supplier Package | SMB Flat |
| Test Current (mA) | 1 |
| SVHC Exceeds Threshold | Yes |
| Supplier Temperature Grade | Automotive |
| Number of Elements per Chip | 1 |
| Maximum Clamping Voltage (V) | 19.5 |
| Minimum Breakdown Voltage (V) | 9.4 |
| Maximum Peak Pulse Current (A) | 205 |
| Peak Pulse Power Dissipation (W) | 600 |
| Maximum Operating Temperature (°C) | 175 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Reverse Leakage Current (uA) | 20 |
| Maximum Reverse Stand-Off Voltage (V) | 8.5 |
| Description |
