Product Attribute | Attribute Value |
Type | Schottky Diode |
Width | 5.6 mm |
Height | 5.6 mm |
Length | 9.53 mm |
Series | SB350 |
Product | Schottky Rectifiers |
Packaging | Cut Tape |
Technology | Si |
Unit Weight | 0.012699 oz |
Configuration | Single |
Mounting Style | Through Hole |
Package / Case | DO-201AD-2 |
If - Forward Current | 3 A |
Ir - Reverse Current | 500 uA |
Vf - Forward Voltage | 740 mV |
Ifsm - Forward Surge Current | 80 A |
Maximum Operating Temperature | + 125 C |
Minimum Operating Temperature | - 65 C |
Vrrm - Repetitive Reverse Voltage | 50 V |
Factory Pack Quantity: Factory Pack Quantity | 1250 |
