Product Attribute | Attribute Value |
Type | Pin Strip |
Pitch | 4.2 mm |
Series | 5566 |
Product | Headers |
Tradename | Mini-Fit Jr. |
Unit Weight | 0.028572 oz |
Housing Color | Natural |
Contact Gender | Pin (Male) |
Current Rating | 9 A |
Mounting Angle | Straight |
Mounting Style | Through Hole |
Number of Rows | 1 Row |
Part # Aliases | 39302035 A-5566-03B3 0039302035 |
Voltage Rating | 600 V |
Contact Plating | Tin |
Contact Material | Tin |
Housing Material | Nylon |
Termination Style | Solder Pin |
Flammability Rating | UL 94 V-2 |
Number of Positions | 3 Position |
Maximum Operating Temperature | + 105 C |
Minimum Operating Temperature | - 40 C |
Factory Pack Quantity: Factory Pack Quantity | 1518 |
