Specification
| Product Attribute | Attribute Value |
| Type | Shrouded |
| Pitch | 5.7 mm |
| Series | 200241 |
| Product | Headers |
| IP Rating | - |
| Tradename | Mega-Fit |
| Application | Power, Wire-to-Board |
| Unit Weight | 0.074781 oz |
| Contact Type | - |
| Housing Color | Black |
| Contact Gender | Pin (Male) |
| Current Rating | 23.5 A |
| Housing Gender | - |
| Mounting Angle | Straight |
| Mounting Style | Through Hole |
| Number of Rows | 1 Row |
| Part # Aliases | 2002411113 02002411113 |
| Voltage Rating | 600 VAC/DC |
| Contact Plating | Tin |
| Contact Material | Copper Alloy |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Termination Style | Solder Pin |
| Flammability Rating | UL 94 V-0 |
| Number of Positions | 3 Position |
| Maximum Operating Temperature | + 105 C |
| Minimum Operating Temperature | - 40 C |
| Factory Pack Quantity: Factory Pack Quantity | 2160 |
| Description |
