Product Attribute | Attribute Value |
Pitch | 6.5 mm |
Series | 151048 |
Packaging | Tube |
Tradename | CP-6.5 |
Unit Weight | 0.060848 oz |
Housing Color | Yellow |
Accessory Type | - |
Contact Gender | Pin (Male) |
Current Rating | 10 A |
Mounting Angle | Straight |
Mounting Style | Mounting Peg |
Number of Rows | 2 Row |
Part # Aliases | 1510482203 01510482203 |
Voltage Rating | 600 VAC/DC |
Contact Plating | Tin |
Contact Material | Copper Alloy |
Housing Material | Polyamide (PA) |
Termination Style | Solder Pin |
Flammability Rating | UL 94 V-0 |
Number of Positions | 2 Position |
Maximum Operating Temperature | + 105 C |
Minimum Operating Temperature | - 40 C |
Factory Pack Quantity: Factory Pack Quantity | 864 |
