Specification
| Product Attribute | Attribute Value |
| Type | Shrouded |
| Pitch | 2.5 mm |
| Series | 105314 |
| Product | Headers |
| Packaging | Tray |
| Tradename | Nano-Fit |
| Application | Power, Wire-to-Board |
| Row Spacing | 2.5 mm |
| Unit Weight | 0.059613 oz |
| Contact Type | - |
| Housing Color | Black |
| Contact Gender | Pin (Male) |
| Current Rating | 7.5 A |
| Housing Gender | - |
| Mounting Angle | Right Angle |
| Mounting Style | Through Hole |
| Number of Rows | 2 Row |
| Part # Aliases | 1053141216 01053141216 |
| Voltage Rating | 300 V |
| Contact Plating | Gold |
| Contact Material | Tin |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Termination Style | Solder Pin |
| Flammability Rating | UL 94 V-0 |
| Number of Positions | 16 Position |
| Termination Post Length | 3.2 mm |
| Maximum Operating Temperature | + 115 C |
| Minimum Operating Temperature | - 40 C |
| Factory Pack Quantity: Factory Pack Quantity | 1 |
| Description |
