Universal Asynchronous Receiver Transmitter- UARTs SC16C650BIB48,157
NXP
SC16C650BIB48,157
--
Drivers and Interfaces
Universal Asynchronous Receiver Transmitter- UARTs
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tray |
| Pin Count | 48 |
| Automotive | No |
| DMA Support | Yes |
| PCB changed | 48 |
| Part Status | Obsolete |
| Package Width | 7.1(Max) |
| Package Height | 1.45(Max) |
| Package Length | 7.1(Max) |
| Supplier Package | LQFP |
| Maximum Data Rate | 3Mbps |
| Process Technology | CMOS |
| Receive FIFO (byte) | 32 |
| Transmit FIFO (byte) | 32 |
| False Start Bit Detection | Yes |
| Supplier Temperature Grade | Industrial |
| Maximum Supply Current (mA) | 4.5 |
| Number of Channels per Chip | 1 |
| Maximum Power Dissipation (mW) | 500 |
| Automatic Hardware Flow Control | Yes |
| Automatic Software Flow Control | Yes |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 2.75|3.63|5.5 |
| Minimum Operating Supply Voltage (V) | 2.25|2.97|4.5 |
| Typical Operating Supply Voltage (V) | 2.5|3.3|5 |
| Transmitter and Receiver FIFO Counter | No |
| Description |
