Transistor and Photovoltaic Output Photocouplers MOC223VM
onsemi
MOC223VM
--
Optoelectronics
Transistor and Photovoltaic Output Photocouplers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Standard | UL|VDE |
| ECCN (US) | EAR99 |
| Packaging | Box |
| Pin Count | 8 |
| Automotive | No |
| Input Type | DC |
| Lead Shape | Gull-wing |
| Output Type | DC |
| PCB changed | 8 |
| Part Status | Obsolete |
| Output Device | Darlington With Base |
| Package Width | 4.16(Max) |
| Package Height | 3.43(Max) |
| Package Length | 5.13(Max) |
| Supplier Package | SOIC N |
| Standard Package Name | SOP |
| Typical Fall Time (us) | 110 |
| Typical Rise Time (us) | 8 |
| Maximum Forward Voltage (V) | 1.3 |
| Maximum Reverse Voltage (V) | 6 |
| Number of Channels per Chip | 1 |
| Typical Forward Voltage (V) | 1.08 |
| Maximum Forward Current (mA) | 60 |
| Maximum Collector Current (mA) | 150 |
| Maximum Power Dissipation (mW) | 250 |
| Minimum Isolation Voltage (Vrms) | 2500 |
| Maximum Current Transfer Ratio (%) | 1000(Typ) |
| Minimum Current Transfer Ratio (%) | 500 |
| Maximum Operating Temperature (°C) | 100 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Collector-Emitter Voltage (V) | 30 |
| Current Transfer Ratio Test Current (mA) | 1 |
| Maximum Collector-Emitter Saturation Voltage (mV) | 1000 |
| Description |
