Transistor and Photovoltaic Output Photocouplers ILCT6-X007
Vishay
ILCT6-X007
--
Optoelectronics
Transistor and Photovoltaic Output Photocouplers
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Standard | BSI|CSA|DIN|EN|UL|VDE |
| ECCN (US) | EAR99 |
| Automotive | No |
| Input Type | DC |
| Output Type | DC |
| Part Status | Obsolete |
| Output Device | Transistor |
| Maximum Forward Voltage (V) | 1.5 |
| Number of Channels per Chip | 2 |
| Typical Forward Voltage (V) | 1.25 |
| Maximum Forward Current (mA) | 60 |
| Maximum Collector Current (mA) | 30 |
| Maximum Power Dissipation (mW) | 400 |
| Minimum Isolation Voltage (Vrms) | 5300 |
| Maximum Current Transfer Ratio (%) | 50(Typ) |
| Minimum Current Transfer Ratio (%) | 20 |
| Maximum Operating Temperature (°C) | 100 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Collector-Emitter Voltage (V) | 30 |
| Current Transfer Ratio Test Current (mA) | 10 |
| Maximum Collector-Emitter Saturation Voltage (mV) | 400 |
| Description |
