Switch Rotary 7829H-1-023LF
Bourns
7829H-1-023LF
--
Electromechanical Switches
Switch Rotary
Specification
| Product Attribute | Attribute Value |
| HTS | 8536.50.90.20 |
| PPAP | No |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Automotive | No |
| Part Status | Active |
| Contact Style | Non-Shorting |
| Actuator Style | Screwdriver |
| Poles per Deck | 1 |
| Body Depth (mm) | 6.35 |
| Number of Decks | 1 |
| Body Height (mm) | 3.94 |
| Body Length (mm) | 6.35 |
| Body Orientation | Straight |
| Termination Style | PC Pins |
| Product Depth (mm) | 6.35 |
| Number of Positions | 2 |
| Number of Terminals | 3 |
| Product Length (mm) | 6.35 |
| Actuator Length (mm) | 0.64 |
| Terminal Length (mm) | 6.78 |
| Mechanical Life (Cycles) | 2000 |
| Pole Throw Configuration | SPDT |
| Maximum Current Rating (A) | 0.1 |
| Maximum Contact Resistance (MOhm) | 2000 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -55 |
| Minimum Insulation Resistance (MOhm) | 10 |
| Description |
