Special Purpose Amplifiers INA281B4IDBVT
Texas Instruments
INA281B4IDBVT
--
Amplifier
Special Purpose Amplifiers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | Current Sense Amplifier |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 5 |
| Automotive | No |
| PCB changed | 5 |
| Part Status | Active |
| Package Width | 1.75(Max) |
| Package Height | 1.1 |
| Package Length | 3.05(Max) |
| Supplier Package | SOT-23 |
| Minimum CMRR (dB) | 120 |
| Minimum PSRR (dB) | 116.48(Typ) |
| Power Supply Type | Single |
| Minimum CMRR Range (dB) | 120 to 130 |
| Maximum Voltage Gain (dB) | 46.02(Typ) |
| Number of Channels per Chip | 1 |
| Number of Elements per Chip | 1 |
| Maximum Input Bias Current (uA) | 30@5V |
| Maximum Voltage Gain Range (dB) | 35 to 50 |
| Maximum Supply Voltage Range (V) | 20 to 30 |
| Maximum Input Offset Voltage (mV) | 0.2@5V |
| Maximum Single Supply Voltage (V) | 20 |
| Minimum Single Supply Voltage (V) | 2.7 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 20 |
| Description |
