Special Purpose Amplifiers AD8275BRMZ
ADI
AD8275BRMZ
--
Amplifier
Special Purpose Amplifiers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | Difference Amplifier |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 8 |
| Part Status | Active |
| Rail to Rail | Rail to Rail Output |
| Package Width | 3 |
| Package Height | 0.85 |
| Package Length | 3 |
| Supplier Package | MSOP |
| Minimum CMRR (dB) | 86 |
| Power Supply Type | Single|Dual |
| Standard Package Name | SOP |
| Minimum CMRR Range (dB) | 75 to 85 |
| Maximum Voltage Gain (dB) | 13.98(Typ) |
| Number of Channels per Chip | 1 |
| Number of Elements per Chip | 1 |
| Typical Output Current (mA) | 3(Max) |
| Maximum Dual Supply Voltage (V) | ±7.5 |
| Maximum Input Resistance (MOhm) | 0.108@5V |
| Maximum Voltage Gain Range (dB) | <35 |
| Minimum Dual Supply Voltage (V) | ±1.65 |
| Typical Dual Supply Voltage (V) | ±3|±5 |
| Maximum Supply Voltage Range (V) | 15 to 18 |
| Maximum Single Supply Voltage (V) | 15 |
| Minimum Single Supply Voltage (V) | 3.3 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | ±7.5|15 |
| Description |
