ATF16V8CZ-15JC
ATF16V8CZ-15JC
Simple Programmable Logic Devices - SPLDs ATF16V8CZ-15JC
Microchip Technology
ATF16V8CZ-15JC
--
Programmable Devices
Simple Programmable Logic Devices - SPLDs
ATF16V8CZ-15JC.pdf
Specification
Product AttributeAttribute Value
HTS8542.31.00.01
PPAPNo
EU RoHSNot Compliant
MountingSurface Mount
ECCN (US)EAR99
Pin Count20
TradenameATF16V8
AutomotiveNo
Lead ShapeJ-Lead
Family NameATF16V8C
PCB changed20
Part StatusObsolete
Speed Grade15
Package Width9.04(Max)
Product Terms8
Package Height3.68(Min)
Package Length9.04(Max)
ProgrammabilityYes
Supplier PackagePLCC
Device System Gates250
Opr. Frequency (MHz)62
Number of Macro Cells8
Standard Package NameLCC
In-System ProgrammabilityNo
Reprogrammability SupportYes
Supplier Temperature GradeCommercial
Maximum Number of User I/Os8
Maximum Operating Current (mA)95
Maximum Operating Temperature (°C)70
Maximum Propagation Delay Time (ns)15
Minimum Operating Temperature (°C)0
Maximum Operating Supply Voltage (V)5.25
Minimum Operating Supply Voltage (V)4.75
Typical Operating Supply Voltage (V)5
Description
SPLD ATF16V8C Family 250 Gates 8 Macro Cells 62MHz 5V 20-Pin PLCC
