TQ2SA24ULCSAJ
TQ2SA24ULCSAJ
Signal Relays TQ2SA24ULCSAJ
Panasonic
TQ2SA24ULCSAJ
--
Relay
Signal Relays
Specification
Product AttributeAttribute Value
PPAPNo
SealSealed
EU RoHSCompliant
MountingSurface Mount
ECCN (US)EAR99
IP RatingIP67
AutomotiveNo
Part StatusUnconfirmed
Contact Form2 Form C
Package TypeDIP
Contact MaterialSilver/Gold Clad
Coil Current (mA)8.3
Operate Time (ms)4
Release Time (ms)4
Termination StyleGull Wing
Product Depth (mm)11.5
Product Weight (g)2
Relay ConstructionNon-Latching
Contact ArrangementDPDT
DC Coil Voltage (V)24
Number of Terminals10
Product Height (mm)5.6
Product Length (mm)14
Coil Resistance (Ohm)2.88K
Maximum Pick-Up Voltage18VDC
Maximum Switching Power30W|62.5VA
Minimum Dropout Voltage2.4VDC
Electrical Life (Operations)100000
Insulation Resistance (MOhm)1000
Mechanical Life (Operations)100000000
Maximum Switching Current (A)2
Maximum AC Switching Voltage (V)125
Maximum DC Switching Voltage (V)220
Maximum Contact Resistance (MOhm)75
Maximum Operating Temperature (°C)85
Minimum Operating Temperature (°C)-40
Description
Signal Relay 24VDC 2A DPDT(14x11.5x5.6)mm SMD
