Product Attribute | Attribute Value |
EU RoHS | Compliant |
ECCN (US) | 3A991.b.2.b |
Packaging | Tray |
Part Status | NRND |
Timing Type | Synchronous |
Architecture | Flow-Through|Pipelined |
Number of Ports | 4 |
Number of Words | 512K |
Chip Density (bit) | 18M |
Process Technology | CMOS |
Max. Access Time (ns) | 7.5@Flow-Through|3.8@Pipelined |
Data Rate Architecture | SDR |
Operating Current (mA) | 200@Flow-Through|215@Pipelined |
Address Bus Width (bit) | 19 |
Maximum Clock Rate (MHz) | 133@Flow-Through|150@Pipelined |
Number of Bits/Word (bit) | 36 |
Supplier Temperature Grade | Industrial |
Maximum Operating Temperature (°C) | 85 |
Minimum Operating Temperature (°C) | -40 |
Maximum Operating Supply Voltage (V) | 2.7|3.6 |
Minimum Operating Supply Voltage (V) | 2.3|3 |
Typical Operating Supply Voltage (V) | 2.5|3.3 |
