3296X-1-105ALF
3296X-1-105ALF
Resistor Trimmers, Potentiometers and Rheostats 3296X-1-105ALF
Bourns
3296X-1-105ALF
--
Resistors
Resistor Trimmers, Potentiometers and Rheostats
Specification
Product AttributeAttribute Value
HTS8533.40.80.50
PPAPNo
SVHCYes
TypeTrimmer
EU RoHSCompliant with Exemption
MountingThrough Hole
ECCN (US)EAR99
PackagingAmmo
Tolerance10%
AutomotiveNo
TechnologyCermet
Part StatusActive
Power Rating (W)0.5 (1/2)
Termination StylePin
Number of Elements1
Product Depth (mm)4.83
Product Weight (g)0.85
Product Height (mm)10.03
Product Length (mm)11.05
Shaft Diameter (mm)2.19
Linear or LogarithmicLin
Resistance Value (Ohm)1M
SVHC Exceeds ThresholdYes
Number of Turns (Turns)25(Elec)
Positions of AdjustmentSide
Electrical Rotation (°)9000
Maximum Voltage Rating (V)300
Temperature Coefficient (ppm/°C)±100
Maximum Operating Temperature (°C)125
Mechanical Rotational Life (Cycles)200
Minimum Operating Temperature (°C)-55
Description
Res Cermet Trimmer 1M Ohm 10% 0.5W(1/2W) 25(Elec)Turns 2.19mm (11.05 X 4.83 X 10.03mm) Pin Thru-Hole Ammo
