Resistor Fixed Single-Other Mounting HL09509Z1R000JJ
Vishay
HL09509Z1R000JJ
--
Resistors
Resistor Fixed Single-Other Mounting
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Not Compliant |
| Mounting | Bolt-On |
| ECCN (US) | EAR99 |
| Packaging | Skin |
| Tolerance | 5% |
| Automotive | No |
| Case Style | Ceramic Hi Temp Sil |
| Technology | Wirewound |
| Part Status | Obsolete |
| Package Type | Flat |
| Package/Case | Flat |
| Package Shape | Tubular |
| Power Rating (W) | 95 |
| Termination Style | Radial Lug |
| Number of Terminals | 2 |
| Product Height (mm) | 14.29 |
| Product Length (mm) | 184.15 |
| Terminal Pitch (mm) | 138.89 |
| Resistance Value (Ohm) | 1 |
| Temperature Coefficient (ppm/°C) | ±50 |
| Maximum Operating Temperature (°C) | 350 |
| Minimum Operating Temperature (°C) | -55 |
| Temperature Range @ Derated Power (°C) | 25 to 350 |
| Description |
