Specification
| Product Attribute | Attribute Value |
| HTS | 8541.10.00.80 |
| PPAP | No |
| SVHC | Yes |
| Type | Switching Diode |
| EU RoHS | Compliant with Exemption |
| Diameter | 3.6(Max) |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 2 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 2 |
| Part Status | Active |
| Configuration | Single |
| Package Length | 7.6(Max) |
| Supplier Package | DO-15 |
| Standard Package Name | DO-204-AC |
| SVHC Exceeds Threshold | Yes |
| Peak Forward Voltage (V) | 0.95 |
| Peak Reverse Current (uA) | 5 |
| Supplier Temperature Grade | Commercial |
| Maximum DC Reverse Voltage (V) | 100 |
| Maximum RMS Reverse Voltage (V) | 70 |
| Peak Reverse Recovery Time (ns) | 15 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -55 |
| Peak Reverse Repetitive Voltage (V) | 100 |
| Peak Non-Repetitive Surge Current (A) | 80 |
| Maximum Continuous Forward Current (A) | 2 |
| Maximum Junction Ambient Thermal Resistance | 45°C/W(Typ) |
| Description |
