Rectifiers SBR10U40CT
Diodes Incorporated
SBR10U40CT
--
Diodes, Transistors and Thyristors
Rectifiers
Specification
| Product Attribute | Attribute Value |
| Tab | Tab |
| PPAP | No |
| SVHC | Yes |
| Type | Super Barrier Rectifier |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 3 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 3 |
| Part Status | Active |
| Configuration | Dual Common Cathode |
| Package Width | 4.82(Max) |
| Package Height | 9.01(Max) |
| Package Length | 10.66(Max) |
| Supplier Package | TO-220AB |
| Standard Package Name | TO-220 |
| SVHC Exceeds Threshold | Yes |
| Peak Forward Voltage (V) | 0.52 |
| Peak Reverse Current (uA) | 500 |
| Maximum DC Reverse Voltage (V) | 40 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -65 |
| Peak Reverse Repetitive Voltage (V) | 40 |
| Peak Non-Repetitive Surge Current (A) | 150 |
| Maximum Continuous Forward Current (A) | 10 |
| Description |
