Rectifiers JANTXV1N5623
Microchip Technology
JANTXV1N5623
--
Diodes, Transistors and Thyristors
Rectifiers
Specification
| Product Attribute | Attribute Value |
| HTS | 8541.10.00.80 |
| PPAP | No |
| SVHC | Yes |
| Type | Switching Diode |
| EU RoHS | Not Compliant |
| Diameter | 2.16(Max) |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Bag |
| Pin Count | 2 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 2 |
| Part Status | Active |
| Configuration | Single |
| Package Length | 6.35(Max) |
| Supplier Package | Case A |
| Standard Package Name | Module |
| SVHC Exceeds Threshold | Yes |
| Peak Forward Voltage (V) | 1.6@3A |
| Peak Reverse Current (uA) | 0.5 |
| Supplier Temperature Grade | Military |
| Maximum DC Reverse Voltage (V) | 1100 |
| Peak Reverse Recovery Time (ns) | 500 |
| Maximum Operating Temperature (°C) | 175 |
| Minimum Operating Temperature (°C) | -65 |
| Peak Reverse Repetitive Voltage (V) | 1000 |
| Peak Non-Repetitive Surge Current (A) | 30 |
| Maximum Continuous Forward Current (A) | 1@Ta=55C |
| Description |
