Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Switching Diode |
| EU RoHS | Compliant with Exemption |
| Diameter | 1.85(Max) |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Pin Count | 2 |
| Automotive | No |
| PCB changed | 2 |
| Part Status | Obsolete |
| Configuration | Single |
| Package Length | 4.25(Max) |
| Supplier Package | ALF |
| Peak Forward Voltage (V) | 1@0.1A |
| Peak Reverse Current (uA) | 5 |
| Maximum DC Reverse Voltage (V) | 75 |
| Maximum Power Dissipation (mW) | 350 |
| Peak Reverse Recovery Time (ns) | 4 |
| Maximum Operating Temperature (°C) | 200 |
| Minimum Operating Temperature (°C) | -65 |
| Peak Reverse Repetitive Voltage (V) | 75 |
| Peak Non-Repetitive Surge Current (A) | 4 |
| Maximum Continuous Forward Current (A) | 0.25 |
| Description |
