Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Schottky Diode |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Box |
| Pin Count | 2 |
| Automotive | No |
| Lead Shape | J-Lead |
| PCB changed | 2 |
| Part Status | Obsolete |
| Configuration | Single |
| Package Width | 3.94(Max) |
| Package Height | 2.24(Max) |
| Package Length | 4.57(Max) |
| Supplier Package | SMB |
| Standard Package Name | DO-214-AA |
| Peak Forward Voltage (V) | 0.44@2A |
| Peak Reverse Current (uA) | 500 |
| Maximum DC Reverse Voltage (V) | 15 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -55 |
| Peak Reverse Repetitive Voltage (V) | 15 |
| Peak Non-Repetitive Surge Current (A) | 140 |
| Maximum Continuous Forward Current (A) | 1 |
| Maximum Junction Ambient Thermal Resistance | 80°C/W |
| Description |
