Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Compliant with Exemption |
| Mounting | Screw |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 15 |
| Automotive | No |
| Lead Shape | Flat |
| PCB changed | 15 |
| Part Status | Obsolete |
| Package Width | 9.07(Max) |
| Package Height | 2.64(Max) |
| Package Length | 23.67(Max) |
| Supplier Package | TO-272 W |
| Manufacturer Type | Wideband Amplifier |
| Power Supply Type | Single |
| Maximum Input VSWR | 5(Typ) |
| Maximum Output VSWR | 5(Typ) |
| Standard Package Name | TO-272 W |
| SVHC Exceeds Threshold | Yes |
| Typical Power Gain (dB) | 30.5@2025MHz |
| Typical Gain Flatness (dB) | 0.1 |
| Typical Output Power (dBm) | 47.78@2025MHz |
| Number of Channels per Chip | 2 |
| Maximum Operating Frequency (MHz) | 2050 |
| Maximum Single Supply Voltage (V) | 32 |
| Minimum Single Supply Voltage (V) | 26 |
| Typical Single Supply Voltage (V) | 28 |
| Typical Power Added Efficiency (%) | 34.7 |
| Maximum Operating Temperature (°C) | 150 |
| Maximum Operating Supply Voltage (V) | 32 |
| Description |
