Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 20 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 20 |
| Part Status | Obsolete |
| Package Width | 4.1(Max) |
| Package Height | 0.95(Max) |
| Package Length | 4.1(Max) |
| Supplier Package | QFN EP |
| Manufacturer Type | Differential Amplifier |
| Power Supply Type | Single |
| Standard Package Name | QFN |
| Typical Power Gain (dB) | 16.5@1000MHz |
| Typical Noise Figure (dB) | 2.75@1000MHz |
| Typical Output Power (dBm) | 23@1000MHz |
| Maximum Supply Current (mA) | 160@5V |
| Number of Channels per Chip | 1 |
| Maximum Input Return Loss (dB) | 17(Typ)@1000MHz |
| Maximum Power Dissipation (mW) | 2160 |
| Maximum Output Return Loss (dB) | 18(Typ)@1000MHz |
| Maximum Operating Frequency (MHz) | 1000 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 5.5 |
| Typical Output Intercept Point (dBm) | 40@1000MHz |
| Description |
