Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| Tab | Tab |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 4 |
| Automotive | No |
| Lead Shape | Flat |
| PCB changed | 3 |
| Part Status | Active |
| Package Width | 2.59(Max) |
| Package Height | 1.6(Max) |
| Package Length | 4.6(Max) |
| Supplier Package | SOT-89 |
| Manufacturer Type | MMIC Amplifier |
| Power Supply Type | Single |
| Standard Package Name | SOT |
| Typical Power Gain (dB) | 15@3000MHz |
| Typical Noise Figure (dB) | 3.5@3000MHz |
| Typical Gain Flatness (dB) | ±0.7 |
| Typical Output Power (dBm) | 17@3000MHz |
| Maximum Supply Current (mA) | 88(Typ)@3000MHz |
| Number of Channels per Chip | 1 |
| Maximum Input Return Loss (dB) | 15(Typ)@3000MHz |
| Maximum Power Dissipation (mW) | 660 |
| Maximum Reverse Isolation (dB) | 21(Typ)@3000MHz |
| Maximum Output Return Loss (dB) | 18(Typ)@3000MHz |
| Maximum Operating Frequency (MHz) | 3000 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 5.5 |
| Typical Output Intercept Point (dBm) | 32@3000MHz |
| Description |
