Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| SVHC | Yes |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 16 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 16 |
| Part Status | Obsolete |
| Package Width | 3.1(Max) |
| Package Height | 0.95(Max) |
| Package Length | 3.1(Max) |
| Supplier Package | QFN EP |
| Manufacturer Type | Power Amplifier |
| Power Supply Type | Single |
| Standard Package Name | QFN |
| SVHC Exceeds Threshold | Yes |
| Typical Power Gain (dB) | 20@5900MHz |
| Typical Noise Figure (dB) | 6@5900MHz |
| Typical Output Power (dBm) | 30@5900MHz |
| Maximum Supply Current (mA) | 750(Typ)@5V |
| Number of Channels per Chip | 1 |
| Maximum Input Return Loss (dB) | 8(Typ)@5900MHz |
| Maximum Power Dissipation (mW) | 4710 |
| Maximum Output Return Loss (dB) | 14(Typ)@5900MHz |
| Maximum Operating Frequency (MHz) | 5900 |
| Maximum Single Supply Voltage (V) | 5.5 |
| Typical Single Supply Voltage (V) | 5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 5.5 |
| Typical Output Intercept Point (dBm) | 43@5900MHz |
| Description |
