Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Packaging | Tape and Reel |
| Pin Count | 7 |
| Automotive | No |
| PCB changed | 7 |
| Part Status | Obsolete |
| Package Width | 1.3 |
| Package Height | 0.45(Max) |
| Package Length | 2 |
| Supplier Package | TSLP |
| Manufacturer Type | Low Noise Amplifier |
| Power Supply Type | Single |
| Standard Package Name | TSLP |
| Typical Power Gain (dB) | 16.2@2140MHz |
| Typical Noise Figure (dB) | 1.1@2140MHz |
| Maximum Supply Current (mA) | 5.8(Typ)@2.75V |
| Number of Channels per Chip | 1 |
| Maximum Input Return Loss (dB) | 7(Typ)@2140MHz |
| Maximum Power Dissipation (mW) | 35 |
| Maximum Output Return Loss (dB) | 13(Typ)@2140MHz |
| Maximum Operating Frequency (MHz) | 6000 |
| Typical Single Supply Voltage (V) | 2.75 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -65 |
| Description |
