Power Transformers hctsm80102aal-e1
Bourns
hctsm80102aal-e1
--
Magnetics
Power Transformers
Specification
| Product Attribute | Attribute Value |
| HTS | 8504.31.20.00 |
| PPAP | Unknown |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Automotive | Yes |
| Lead Style | Gull Wing |
| Part Status | Active |
| Turns Ratio | 1:2 |
| Package Type | SMD |
| High Potential | 5000VAC |
| Transformer Type | High Clearance and Creepage Distance Transformer |
| Product Depth (mm) | 15.2 |
| Number of Terminals | 6 |
| Product Height (mm) | 6.5 |
| Product Length (mm) | 10.8 |
| Primary Configuration | Dual |
| Primary Side Connection | Parallel|Series |
| Secondary Configuration | Dual |
| Primary Side Voltage (V) | 800 |
| Secondary Side Connection | Parallel|Series |
| Primary Side Inductance (uH) | 250 |
| Maximum DCR Primary Side (Ohm) | 0.3 |
| Maximum DCR Secondary Side (Ohm) | 0.35 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Description |
