DC1961A
DC1961A
Power Management Development Boards and Kits DC1961A
ADI
DC1961A
--
Power Management
Power Management Development Boards and Kits
DC1961A.pdf
Specification
Product AttributeAttribute Value
PPAPNo
TypeDemonstration Circuit
EU RoHSCompliant
ECCN (US)EAR99
AutomotiveNo
Part StatusActive
Efficiency (%)91.5
Supported DeviceLT8309
Number of Outputs1
Input Voltage Range36VDC to 72VDC
Output Current (mA)5000
Switching Frequency (kHz)133
Output Voltage Range (VDC)11.4 to 12.6
Supported Device TechnologyGate and Power Driver
Description
LT8309ES5/LT3748EMS Isolated Demo Board, 36V ≤ VIN ≤ 72V; VOUT = 12V @ 5A
