Specification
| Product Attribute | Attribute Value |
| PPAP | Unknown |
| SVHC | Yes |
| Type | High Speed Amplifier |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 16 |
| Automotive | Yes |
| Lead Shape | Gull-wing |
| PCB changed | 16 |
| Part Status | Obsolete |
| Package Width | 3.9 |
| Package Height | 1.25(Min) |
| Package Length | 9.9 |
| Supplier Package | SO |
| Manufacturer Type | High Speed Amplifier |
| Minimum CMRR (dB) | 80 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Process Technology | Bipolar |
| Standard Package Name | SOP |
| Minimum CMRR Range (dB) | 80 to 85 |
| Typical Slew Rate (V/us) | 110@±5V |
| Typical Voltage Gain (dB) | 70 |
| Supplier Temperature Grade | Automotive |
| Number of Channels per Chip | 4 |
| Maximum Quiescent Current (mA) | 24@±5V |
| Maximum Dual Supply Voltage (V) | ±6 |
| Maximum Input Bias Current (uA) | 15@±5V |
| Minimum Dual Supply Voltage (V) | ±3.5 |
| Typical Dual Supply Voltage (V) | ±5 |
| Maximum Input Offset Current (uA) | 2@±5V |
| Maximum Input Offset Voltage (mV) | 4@±5V |
| Maximum Single Supply Voltage (V) | 12 |
| Minimum Single Supply Voltage (V) | 7 |
| Typical Single Supply Voltage (V) | 9 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 150 |
| Typical Input Noise Voltage Density (nV/rtHz) | 4.2@±5V |
| Description |
