Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | Unknown |
| SVHC | Yes |
| Type | Low Noise Amplifier |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 14 |
| Automotive | Yes |
| Lead Shape | Gull-wing |
| PCB changed | 14 |
| Part Status | Active |
| Package Width | 4(Max) |
| Package Height | 1.65(Max) |
| Package Length | 8.75(Max) |
| Supplier Package | SOIC |
| Manufacturer Type | Low Noise Amplifier |
| Minimum CMRR (dB) | 70 |
| Power Supply Type | Dual |
| Shut Down Support | No |
| Process Technology | BiFET |
| Standard Package Name | SOP |
| Minimum CMRR Range (dB) | 70 to 71 |
| Typical Slew Rate (V/us) | 13@±15V |
| Typical Voltage Gain (dB) | 106.02 |
| Number of Channels per Chip | 4 |
| Maximum Power Dissipation (mW) | 680 |
| Maximum Quiescent Current (mA) | 2.5@±15V |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Bias Current (uA) | 0.0002@±15V |
| Minimum Dual Supply Voltage (V) | ±3 |
| Typical Dual Supply Voltage (V) | ±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) | 0.0001@±15V |
| Maximum Input Offset Voltage (mV) | 10@±15V |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Typical Gain Bandwidth Product (MHz) | 3 |
| Typical Input Noise Voltage Density (nV/rtHz) | 15@±15V |
| Description |
