Op Amps TL052AIP
Texas Instruments
TL052AIP
--
Amplifier
Op Amps
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | Low Offset Voltage Amplifier |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 8 |
| Part Status | Active |
| Package Width | 6.6(Max) |
| Package Height | 5.08(Max) - 0.51(Min) |
| Package Length | 10.16(Max) |
| Supplier Package | PDIP |
| Manufacturer Type | Low Offset Voltage Amplifier |
| Minimum CMRR (dB) | 65 |
| Power Supply Type | Dual |
| Shut Down Support | No |
| Process Technology | BiFET |
| Standard Package Name | DIP |
| Minimum CMRR Range (dB) | 65 to 70 |
| Typical Slew Rate (V/us) | 17.8@±5V |
| Typical Voltage Gain (dB) | 95.42 |
| Number of Channels per Chip | 2 |
| Typical Output Current (mA) | 80(Max) |
| Maximum Quiescent Current (mA) | 5.6@±5V |
| Maximum Dual Supply Voltage (V) | ±15 |
| Maximum Input Bias Current (uA) | 0.0002@±5V |
| Minimum Dual Supply Voltage (V) | ±5 |
| Typical Dual Supply Voltage (V) | ±9|±12 |
| Maximum Input Offset Current (uA) | 0.0001@±5V |
| Maximum Input Offset Voltage (mV) | 2.8@±5V |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 3 |
| Typical Input Noise Voltage Density (nV/rtHz) | 71@±5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.01@±5V |
| Description |
