Op Amps THS4011MFKB
Texas Instruments
THS4011MFKB
--
Amplifier
Op Amps
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | High Speed Amplifier |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 20 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 20 |
| Part Status | Active |
| Package Width | 9.09(Max) |
| Package Height | 2.03(Max) |
| Package Length | 9.09(Max) |
| Supplier Package | CLLCC |
| Manufacturer Type | High Speed Amplifier |
| Minimum CMRR (dB) | 84 |
| Minimum PSRR (dB) | 80 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Process Technology | BiCOM |
| Standard Package Name | LLCC |
| Minimum CMRR Range (dB) | 80 to 85 |
| Typical Slew Rate (V/us) | 400@±15V |
| Typical Voltage Gain (dB) | 80 |
| Supplier Temperature Grade | Military |
| Typical Settling Time (ns) | 70 |
| Number of Channels per Chip | 1 |
| Typical Output Current (mA) | 75@±5V |
| Maximum Power Dissipation (mW) | 1375 |
| Maximum Dual Supply Voltage (V) | ±16.5 |
| Maximum Input Bias Current (uA) | 6@±5V |
| Minimum Dual Supply Voltage (V) | ±4.5 |
| Typical Dual Supply Voltage (V) | ±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) | 0.25@±5V |
| Maximum Input Offset Voltage (mV) | 6@±5V |
| Maximum Single Supply Voltage (V) | 33 |
| Minimum Single Supply Voltage (V) | 9 |
| Typical Single Supply Voltage (V) | 12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -55 |
| Typical Gain Bandwidth Product (MHz) | 200 |
| Typical Input Noise Voltage Density (nV/rtHz) | 7.5@±5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 1@±5V |
| Description |
