Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| SVHC | Yes |
| Type | Low Voltage Amplifier |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Pin Count | 14 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 14 |
| Part Status | Obsolete |
| Package Width | 6.35 |
| Package Height | 3.3 |
| Package Length | 19.05 |
| Supplier Package | PDIP N |
| Manufacturer Type | Low Voltage Amplifier |
| Minimum CMRR (dB) | 80 |
| Minimum PSRR (dB) | 109.9(Typ) |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Process Technology | Bipolar |
| Standard Package Name | DIP |
| SVHC Exceeds Threshold | Yes |
| Minimum CMRR Range (dB) | 80 to 85 |
| Typical Slew Rate (V/us) | 0.012@±15V |
| Typical Voltage Gain (dB) | 118.06 |
| Maximum Supply Current (mA) | 0.08@±15V |
| Number of Channels per Chip | 4 |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Bias Current (uA) | 0.025@±15V |
| Minimum Dual Supply Voltage (V) | ±0.8 |
| Typical Dual Supply Voltage (V) | ±3|±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) | 0.005@±15V |
| Maximum Input Offset Voltage (mV) | 1@±15V |
| Maximum Single Supply Voltage (V) | 36 |
| Minimum Single Supply Voltage (V) | 1.6 |
| Typical Single Supply Voltage (V) | 3|5|9|12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 0.02 |
