Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | General Purpose Amplifier |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 6 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 6 |
| Part Status | Obsolete |
| Rail to Rail | Rail to Rail Output |
| Package Width | 1.6 |
| Package Height | 0.5(Max) |
| Package Length | 1.6 |
| Supplier Package | UDFN EP |
| Manufacturer Type | General Purpose Amplifier |
| Minimum CMRR (dB) | 65 |
| Minimum PSRR (dB) | 70 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Standard Package Name | DFN |
| Minimum CMRR Range (dB) | 65 to 70 |
| Typical Slew Rate (V/us) | 2.3@5V |
| Typical Voltage Gain (dB) | 127 |
| Typical Settling Time (ns) | 2000 |
| Number of Channels per Chip | 1 |
| Typical Output Current (mA) | 8@5V |
| Maximum Power Dissipation (mW) | 200 |
| Maximum Quiescent Current (mA) | 0.66@5V |
| Maximum Dual Supply Voltage (V) | ±8 |
| Maximum Input Bias Current (uA) | 0.00015@5V |
| Minimum Dual Supply Voltage (V) | ±1.25 |
| Typical Dual Supply Voltage (V) | ±5|±3 |
| Typical Input Bias Current (uA) | 0.000045@5V |
| Maximum Input Offset Current (uA) | 0.00015@5V |
| Maximum Input Offset Voltage (mV) | 5@5V |
| Maximum Single Supply Voltage (V) | 16 |
| Minimum Single Supply Voltage (V) | 2.5 |
| Typical Single Supply Voltage (V) | 3|5|9|12|15 |
| Maximum Operating Temperature (°C) | 125 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 3.5 |
| Typical Input Noise Voltage Density (nV/rtHz) | 30@5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.0006@5V |
| Description |
