Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | Low Noise Amplifier |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 14 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 14 |
| Part Status | Active |
| Package Width | 6.48 |
| Package Height | 3.3 |
| Package Length | 19.56(Max) |
| Supplier Package | PDIP N |
| Manufacturer Type | Low Noise Amplifier |
| Minimum CMRR (dB) | 112 |
| Minimum PSRR (dB) | 116 |
| Power Supply Type | Dual |
| Shut Down Support | No |
| Standard Package Name | DIP |
| Minimum CMRR Range (dB) | 105 to 115 |
| Typical Slew Rate (V/us) | 4.5@±15V |
| Typical Voltage Gain (dB) | 144.61 |
| Supplier Temperature Grade | Commercial |
| Maximum Supply Current (mA) | 11@±15V |
| Number of Channels per Chip | 4 |
| Maximum Dual Supply Voltage (V) | ±22 |
| Maximum Input Bias Current (uA) | 0.02@±15V |
| Minimum Dual Supply Voltage (V) | ±4 |
| Typical Dual Supply Voltage (V) | ±5|±9|±12|±15|±18 |
| Maximum Input Offset Current (uA) | 0.02@±15V |
| Maximum Input Offset Voltage (mV) | 0.09@±15V |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Typical Gain Bandwidth Product (MHz) | 12.5 |
| Typical Input Noise Voltage Density (nV/rtHz) | 3@±15V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 1.3@±15V |
| Description |
