Op Amps LT1014DIN
Texas Instruments
LT1014DIN
--
Amplifier
Op Amps
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| Type | Precision Amplifier |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 14 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 14 |
| Part Status | Active |
| Package Width | 6.6(Max) |
| Package Height | 5.08(Max) - 0.51(Min) |
| Package Length | 19.69(Max) |
| Supplier Package | PDIP |
| Manufacturer Type | Precision Amplifier |
| Minimum CMRR (dB) | 97 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Standard Package Name | DIP |
| Minimum CMRR Range (dB) | 95 to 105 |
| Typical Slew Rate (V/us) | 0.4@±15V |
| Typical Voltage Gain (dB) | 120 |
| Maximum Supply Current (mA) | 2@5V |
| Number of Channels per Chip | 4 |
| Maximum Power Dissipation (mW) | 1150 |
| Maximum Dual Supply Voltage (V) | ±22 |
| Maximum Input Bias Current (uA) | 0.05@5V |
| Minimum Dual Supply Voltage (V) | ±2.5 |
| Typical Dual Supply Voltage (V) | ±15 |
| Maximum Input Offset Current (uA) | 0.002@5V |
| Maximum Input Offset Voltage (mV) | 0.95@5V |
| Maximum Single Supply Voltage (V) | 44 |
| Minimum Single Supply Voltage (V) | 5 |
| Typical Single Supply Voltage (V) | 9|12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 105 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 1 |
| Typical Input Noise Voltage Density (nV/rtHz) | 24@±15V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 0.07@±15V |
| Description |
