Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| SVHC | Yes |
| Type | General Purpose Amplifier |
| EU RoHS | Not Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 14 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 14 |
| Part Status | Obsolete |
| Package Width | 4(Max) |
| Package Height | 1.5(Max) |
| Package Length | 8.75(Max) |
| Supplier Package | SOIC N |
| Manufacturer Type | General Purpose Amplifier |
| Minimum CMRR (dB) | 70 |
| Minimum PSRR (dB) | 65 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Process Technology | Bipolar |
| Standard Package Name | SOP |
| SVHC Exceeds Threshold | Yes |
| Minimum CMRR Range (dB) | 70 to 71 |
| Typical Voltage Gain (dB) | 100 |
| Maximum Supply Current (mA) | 1.2@5V@-25C to 85C |
| Number of Channels per Chip | 4 |
| Typical Output Current (mA) | 40@15V |
| Maximum Dual Supply Voltage (V) | ±16 |
| Maximum Input Bias Current (uA) | 0.15@5V |
| Minimum Dual Supply Voltage (V) | ±1.5 |
| Typical Dual Supply Voltage (V) | ±15|±12|±9|±5|±3 |
| Maximum Input Offset Current (uA) | 0.03@5V |
| Maximum Input Offset Voltage (mV) | 5@30V |
| Maximum Single Supply Voltage (V) | 32 |
| Minimum Single Supply Voltage (V) | 3 |
| Typical Single Supply Voltage (V) | 28|24|18|15|12|9|5 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -25 |
| Description |
