Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | High Gain Amplifier |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Rail |
| Pin Count | 9 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 9 |
| Part Status | Obsolete |
| Package Width | 3 |
| Package Height | 5.8 |
| Package Length | 22.24(Max) |
| Supplier Package | SIP |
| Manufacturer Type | High Gain Amplifier |
| Minimum CMRR (dB) | 65 |
| Minimum PSRR (dB) | 65 |
| Power Supply Type | Single|Dual |
| Shut Down Support | No |
| Process Technology | Bipolar |
| Standard Package Name | SIP |
| Minimum CMRR Range (dB) | 65 to 70 |
| Typical Voltage Gain (dB) | 100 |
| Maximum Supply Current (mA) | 1.2@5V |
| Number of Channels per Chip | 2 |
| Typical Output Current (mA) | 30@15V |
| Maximum Dual Supply Voltage (V) | ±16 |
| Maximum Input Bias Current (uA) | 0.25@5V |
| Minimum Dual Supply Voltage (V) | ±1.5 |
| Typical Dual Supply Voltage (V) | ±3|±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) | 0.05@5V |
| Maximum Input Offset Voltage (mV) | 7@5V |
| Maximum Single Supply Voltage (V) | 32 |
| Minimum Single Supply Voltage (V) | 3 |
| Typical Single Supply Voltage (V) | 5|9|12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Description |
