Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| Type | Monolithic Amplifier |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Rail |
| Pin Count | 14 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 14 |
| Part Status | Obsolete |
| Package Width | 6.6(Max) |
| Package Height | 3.56(Max) |
| Package Length | 19.56(Max) |
| Supplier Package | PDIP |
| Manufacturer Type | Monolithic Amplifier |
| Minimum CMRR (dB) | 70 |
| Minimum PSRR (dB) | 76.48(Max) |
| Power Supply Type | Dual|Single |
| Shut Down Support | No |
| Process Technology | Bipolar |
| Standard Package Name | DIP |
| Minimum CMRR Range (dB) | 70 to 71 |
| Typical Slew Rate (V/us) | 0.4@±15V |
| Typical Voltage Gain (dB) | 106.02 |
| Maximum Supply Current (mA) | 7@5V |
| Number of Channels per Chip | 4 |
| Maximum Power Dissipation (mW) | 670 |
| Maximum Dual Supply Voltage (V) | ±18 |
| Maximum Input Bias Current (uA) | 0.5@5V |
| Minimum Dual Supply Voltage (V) | ±1.5 |
| Typical Dual Supply Voltage (V) | ±3|±5|±9|±12|±15 |
| Maximum Input Offset Current (uA) | 0.05@5V |
| Maximum Input Offset Voltage (mV) | 10@5V |
| Maximum Single Supply Voltage (V) | 36 |
| Minimum Single Supply Voltage (V) | 3 |
| Typical Single Supply Voltage (V) | 5|9|12|15|18|24|28 |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | 0 |
| Typical Gain Bandwidth Product (MHz) | 0.009 |
| Description |
