Specification
| Product Attribute | Attribute Value |
| HTS | 8542.33.00.01 |
| PPAP | No |
| SVHC | Yes |
| Type | High Speed Amplifier |
| EU RoHS | Not Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 8 |
| Part Status | Obsolete |
| Package Width | 6.35 |
| Package Height | 3.3 |
| Package Length | 9.27 |
| Supplier Package | PDIP N |
| Manufacturer Type | High Speed Amplifier |
| Minimum CMRR (dB) | 70 |
| Minimum PSRR (dB) | 50 |
| Power Supply Type | Dual |
| Shut Down Support | No |
| Standard Package Name | DIP |
| SVHC Exceeds Threshold | Yes |
| Minimum CMRR Range (dB) | 70 to 71 |
| Typical Slew Rate (V/us) | 1300@±5V |
| Typical Voltage Gain (dB) | 52 |
| Supplier Temperature Grade | Industrial |
| Typical Settling Time (ns) | 16 |
| Number of Channels per Chip | 1 |
| Typical Output Current (mA) | 70@±5V |
| Maximum Power Dissipation (mW) | 1300 |
| Maximum Dual Supply Voltage (V) | ±6 |
| Maximum Input Bias Current (uA) | 7@±5V |
| Minimum Dual Supply Voltage (V) | ±3 |
| Typical Dual Supply Voltage (V) | ±5 |
| Maximum Input Offset Current (uA) | 3@±5V |
| Maximum Input Offset Voltage (mV) | 10@±5V |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Typical Gain Bandwidth Product (MHz) | 110 |
| Typical Input Noise Voltage Density (nV/rtHz) | 7@±5V |
| Typical Noninverting Input Current Noise Density (pA/rtHz) | 2.5@±5V |
| Description |
