Multiplexers MC100EL58DR2G
onsemi
MC100EL58DR2G
--
Standard and Specialty Logic
Multiplexers
Specification
| Product Attribute | Attribute Value |
| HTS | 8542.39.00.01 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| Polarity | Inverting/Non-Inverting |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 8 |
| Automotive | No |
| Lead Shape | Gull-wing |
| PCB changed | 8 |
| Part Status | Active |
| Logic Family | ECL |
| Configuration | 1 x 2:1 |
| Package Width | 4(Max) |
| Logic Function | Multiplexer |
| Package Height | 1.5(Max) |
| Package Length | 5(Max) |
| Supplier Package | SOIC N |
| Input Signal Type | Single-Ended |
| Power Supply Type | Single |
| Output Signal Type | Differential |
| Process Technology | ECL |
| Parity Invert Input | No |
| Standard Package Name | SOP |
| Maximum Frequency (MHz) | 1500(Typ) |
| Number of Inputs per Chip | 2 |
| Number of Outputs per Chip | 1 |
| Number of Elements per Chip | 1 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Number of Input Enables per Element | 0 |
| Absolute Propagation Delay Time (ns) | 0.41 |
| Maximum Operating Supply Voltage (V) | -5.7|5.7 |
| Minimum Operating Supply Voltage (V) | -4.2|4.2 |
| Number of Output Enables per Element | 0 |
| Typical Operating Supply Voltage (V) | -5|5 |
| Maximum Low Level Output Current (mA) | 50 |
| Maximum High Level Output Current (mA) | -50 |
| Number of Selection Inputs per Element | 1 |
| Maximum Propagation Delay Time @ Maximum CL (ns) | 0.34@5V |
| Description |
