Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Pin Count | 4 |
| Automotive | No |
| Lead Shape | Through Hole |
| PCB changed | 4 |
| Part Status | Active |
| Channel Mode | Enhancement |
| Channel Type | N |
| Configuration | Single Dual Drain |
| Package Width | 6.29(Max) |
| Package Height | 3.37(Max) |
| Package Length | 5(Max) |
| Product Category | Power MOSFET |
| Supplier Package | HVMDIP |
| Standard Package Name | DIP |
| Typical Fall Time (ns) | 27 |
| Typical Rise Time (ns) | 64 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation (mW) | 1300 |
| Typical Gate Charge @ Vgs (nC) | 12(Max)@5V |
| Maximum Gate Source Voltage (V) | ±10 |
| Typical Turn-On Delay Time (ns) | 9.8 |
| Maximum Drain Source Voltage (V) | 100 |
| Typical Turn-Off Delay Time (ns) | 21 |
| Maximum Operating Temperature (°C) | 175 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Continuous Drain Current (A) | 1.3 |
| Typical Input Capacitance @ Vds (pF) | 490@25V |
| Maximum Drain Source Resistance (MOhm) | 270@5V |
| Description |
