Specification
| Product Attribute | Attribute Value |
| HTS | 8541.29.00.95 |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 6 |
| Automotive | No |
| PCB changed | 6 |
| Part Status | Obsolete |
| Channel Mode | Enhancement |
| Channel Type | P |
| Configuration | Dual |
| Package Width | 1.3(Max) |
| Package Height | 0.6(Max) |
| Package Length | 1.7(Max) |
| Product Category | Power MOSFET |
| Supplier Package | SOT-563F |
| Process Technology | TMOS |
| Standard Package Name | SOT |
| Typical Fall Time (ns) | 1 |
| Typical Rise Time (ns) | 13 |
| Number of Elements per Chip | 2 |
| Maximum Power Dissipation (mW) | 625 |
| Typical Gate Charge @ Vgs (nC) | 1@4.5V |
| Maximum Gate Source Voltage (V) | ±8 |
| Typical Turn-On Delay Time (ns) | 6 |
| Maximum Drain Source Voltage (V) | 20 |
| Typical Turn-Off Delay Time (ns) | 8 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Continuous Drain Current (A) | 0.35 |
| Typical Input Capacitance @ Vds (pF) | 100@10V |
| Maximum Drain Source Resistance (mOhm) | 1200@4.5V |
| Description |
