MOSFETs FDWS86368-F085
onsemi
FDWS86368-F085
--
Diodes, Transistors and Thyristors
MOSFETs
Specification
| Product Attribute | Attribute Value |
| HTS | 8541.29.00.95 |
| PPAP | Yes |
| SVHC | Yes |
| EU RoHS | Compliant with Exemption |
| Mounting | Surface Mount |
| ECCN (US) | EAR99 |
| Packaging | Tape and Reel |
| Pin Count | 8 |
| Automotive | Yes |
| PCB changed | 8 |
| Part Status | Active |
| Channel Mode | Enhancement |
| Channel Type | N |
| Configuration | Single Quad Drain Triple Source |
| Package Width | 5.9(Max) |
| Package Height | 1.05(Max) |
| Package Length | 5(Max) |
| Product Category | Power MOSFET |
| Supplier Package | DFN EP |
| Maximum IDSS (uA) | 1 |
| Process Technology | TMOS |
| SVHC Exceeds Threshold | Yes |
| Typical Fall Time (ns) | 13 |
| Typical Rise Time (ns) | 22 |
| Supplier Temperature Grade | Automotive |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation (mW) | 214000 |
| Typical Gate Charge @ 10V (nC) | 57 |
| Typical Gate Charge @ Vgs (nC) | 57@10V |
| Maximum Gate Source Voltage (V) | ±20 |
| Typical Turn-On Delay Time (ns) | 23 |
| Maximum Drain Source Voltage (V) | 80 |
| Typical Turn-Off Delay Time (ns) | 32 |
| Maximum Gate Threshold Voltage (V) | 4 |
| Maximum Operating Temperature (°C) | 175 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Continuous Drain Current (A) | 80 |
| Typical Input Capacitance @ Vds (pF) | 4350@40V |
| Maximum Drain Source Resistance (mOhm) | 4.5@10V |
| Maximum Gate Source Leakage Current (nA) | 100 |
| Description |
