MOSFETs APTM100A13DG
Microchip Technology
APTM100A13DG
--
Diodes, Transistors and Thyristors
MOSFETs
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Screw |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 7 |
| Automotive | No |
| PCB changed | 7 |
| Part Status | Active |
| Channel Mode | Enhancement |
| Channel Type | N |
| Configuration | Dual |
| Package Width | 62 |
| Package Height | 15 |
| Package Length | 108 |
| Product Category | Power MOSFET |
| Supplier Package | Case SP-6 |
| Typical Fall Time (ns) | 24 |
| Typical Rise Time (ns) | 9 |
| Number of Elements per Chip | 2 |
| Maximum Power Dissipation (mW) | 1250000 |
| Typical Gate Charge @ 10V (nC) | 562 |
| Typical Gate Charge @ Vgs (nC) | 562@10V |
| Maximum Gate Source Voltage (V) | ±30 |
| Typical Turn-On Delay Time (ns) | 9 |
| Maximum Drain Source Voltage (V) | 1000 |
| Typical Turn-Off Delay Time (ns) | 50 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Continuous Drain Current (A) | 65 |
| Typical Input Capacitance @ Vds (pF) | 15200@25V |
| Maximum Drain Source Resistance (MOhm) | 156@10V |
| Description |
