MOSFETs APT20M18LVRG
Microchip Technology
APT20M18LVRG
--
Diodes, Transistors and Thyristors
MOSFETs
Specification
| Product Attribute | Attribute Value |
| HTS | 8541.21.00.95 |
| Tab | Tab |
| PPAP | No |
| EU RoHS | Compliant |
| Mounting | Through Hole |
| ECCN (US) | EAR99 |
| Packaging | Tube |
| Pin Count | 3 |
| Automotive | No |
| PCB changed | 3 |
| Part Status | Active |
| Channel Mode | Enhancement |
| Channel Type | N |
| Configuration | Single |
| Package Width | 5.21(Max) |
| Package Height | 26.49(Max) |
| Package Length | 20.5(Max) |
| Product Category | Power MOSFET |
| Supplier Package | TO-264 |
| Typical Fall Time (ns) | 6 |
| Typical Rise Time (ns) | 27 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation (mW) | 625000 |
| Typical Gate Charge @ 10V (nC) | 330 |
| Typical Gate Charge @ Vgs (nC) | 330@10V |
| Maximum Gate Source Voltage (V) | ±30 |
| Typical Turn-On Delay Time (ns) | 18 |
| Maximum Drain Source Voltage (V) | 200 |
| Typical Turn-Off Delay Time (ns) | 55 |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | -55 |
| Maximum Continuous Drain Current (A) | 100 |
| Typical Input Capacitance @ Vds (pF) | 9880@25V |
| Maximum Drain Source Resistance (MOhm) | 18@15V |
| Description |
