TLS820B2ELVSEXUMA1
TLS820B2ELVSEXUMA1
Linear Regulators TLS820B2ELVSEXUMA1
Infineon
TLS820B2ELVSEXUMA1
--
Power Management
Linear Regulators
TLS820B2ELVSEXUMA1.pdf
Specification
Product AttributeAttribute Value
HTS8542330001
PPAPUnknown
TypeLDO
EU RoHSCompliant
MountingSurface Mount
PolarityPositive
ECCN (US)EAR99
PackagingTape and Reel
Pin Count14
AutomotiveYes
Output TypeFixed
PCB changed14
Part StatusActive
Accuracy (%)±2
Package Width3.9
Package Height1.45
Package Length4.9
Line Regulation1mV(Typ)
Load Regulation-5mV(Typ)
Junction to Case10K/W(Typ)
Special FeaturesCurrent Limit|Short Circuit Protection
Supplier PackageSSOP EP
Number of Outputs1
Output Voltage (V)3.3|5
Junction to Ambient125K/W(Typ)
Maximum Input Voltage (V)40
Minimum Input Voltage (V)3
Maximum Output Current (A)0.2
Maximum Quiescent Current (mA)0.025
Maximum Operating Temperature (°C)150
Minimum Operating Temperature (°C)-40
Maximum Dropout Voltage @ Current (V)0.4@200mA|0.2@100mA
Description
LDO Regulator Pos 3.3V5V 0.2A Automotive 14-Pin SSOP EP T/R
