Specification
| Product Attribute | Attribute Value |
| Tab | Tab |
| PPAP | No |
| SVHC | Yes |
| Type | LDO |
| EU RoHS | Compliant with Exemption |
| Mounting | Through Hole |
| Polarity | Positive |
| ECCN (US) | EAR99 |
| Pin Count | 3 |
| Automotive | No |
| Lead Shape | Through Hole |
| Output Type | Adjustable |
| PCB changed | 3 |
| Part Status | Obsolete |
| Package Width | 5.26(Max) |
| Package Height | 22.1(Max) |
| Package Length | 16.26(Max) |
| Line Regulation | 0.2% |
| Load Regulation | 0.3% |
| Junction to Case | 2.3°C/W |
| Special Features | Current Limit|Safe Area Protection|Short Circuit Protection|Thermal Shutdown Protection |
| Supplier Package | TO-3P |
| Number of Outputs | 1 |
| Output Voltage (V) | 1.25 to 28.5 |
| Junction to Ambient | 35°C/W |
| Reference Voltage (V) | 1.262 |
| Standard Package Name | TO-3P |
| SVHC Exceeds Threshold | Yes |
| Maximum Input Voltage (V) | 30 |
| Minimum Input Voltage (V) | 2.55 |
| Maximum Output Current (A) | 5 |
| Supplier Temperature Grade | Commercial |
| Maximum Operating Temperature (°C) | 150 |
| Minimum Operating Temperature (°C) | 0 |
| Maximum Dropout Voltage @ Current (V) | 1.5 |
| Description |
