LVDS LMH0070SQX/NOPB
Texas Instruments
LMH0070SQX/NOPB
--
Drivers and Interfaces
LVDS
Specification
| Product Attribute | Attribute Value |
| PPAP | No |
| EU RoHS | Compliant |
| Function | Serializer |
| Mounting | Surface Mount |
| ECCN (US) | 5A991.b.1 |
| Packaging | Tape and Reel |
| Pin Count | 48 |
| Automotive | No |
| Lead Shape | No Lead |
| PCB changed | 48 |
| Part Status | Unconfirmed |
| Package Width | 7.15(Max) |
| Package Height | 0.8(Max) - 0.05 |
| Package Length | 7.15(Max) |
| Supplier Package | WQFN EP |
| Input Signal Type | LVCMOS|LVDS |
| Number of Drivers | 1 |
| Number of Receivers | 5 |
| Standard Package Name | QFN |
| Maximum Input Current (uA) | 35 |
| Number of Elements per Chip | 1 |
| Transmission Data Rate (MBps) | 3000 |
| Maximum Power Dissipation (mW) | 440(Typ) |
| Maximum Operating Frequency (MHz) | 297 |
| Minimum Operating Frequency (MHz) | 27 |
| Maximum Operating Temperature (°C) | 85 |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Supply Voltage (V) | 2.625|3.465 |
| Minimum Operating Supply Voltage (V) | 2.375|3.135 |
| Typical Operating Supply Voltage (V) | 2.5|3.3 |
| Differential Input Low Threshold Voltage (V) | -0.1 |
| Differential Input High Threshold Voltage (V) | 0.1 |
| Description |
